Entry-level CNC, Pro-level Power
Sign up and get an exclusive gift with your Makera Z1 purchase
Exclusive Gifts
for pioneers before
June 30.
Points
on your Z1 purchase.
Use them to save big on
future purchase.
Limited Batch 1
available for Mid-July
shipping. Pre-order now
to secure Batch 1 priority
before we shift to the next
fulfillment window
Add-ons
and get up to 25% off Z1
accessories and add-ons
during this event.
Tired of printing plastics and ending up with fragile parts?
Time to set up to CNC and unlock real strength.
Cut and shape almost any material
After years of innovation, we present our latest technologies.
Quick Tool Change
Swap Tools in Seconds, No Downtime
Z1’s quick-change mechanism lets you replace cutting or engraving tools in seconds. No more stopping for manual adjustments—workflow stays smooth and efficient.
Auto Probing & Leveling
No More Manual Adjustments
Z1 probes the workpiece to detect thickness and surface position, then levels it in real time for accurate alignment before machining.
All-New AeroDust™ Collection System
Clean Workspace, Maximum Output.
The Z1 features an integrated high-pressure blower and duct system that not only dissipates heat but also effectively removes debris during machining. The bottom dust port ensures a clean workspace, optimizing efficiency with every cut.
One Piece Cast Frame
Precision and Stability in Every Frame
Crafted with precision, the lightweight frame of the Z1 delivers an unwavering foundation for high-precision machining. Its robust structure ensures that every cut, carve, and design maintains absolute accuracy, even in the most demanding tasks.
Built-in Camera
Stay Connected with Seamless Monitoring
With the built-in camera, the Z1 allows you to monitor the machining process remotely in real time. The time-lapse feature makes it easy to capture and share the entire creation process, giving you a seamless way to showcase your work.
Quiet, Enclosed Frame
Operate Smoothly, Minimize Noise
Z1’s fully enclosed design keeps noise and dust contained, creating a safer and quieter workspace. Focus on your work without distractions, while maintaining a clean and controlled environment.
Better accessories for greater creativity
Intelligent Toolpaths, Ready in Minutes
The First One-Click Consumer CAM Software. From the start, we knew software was CNC's biggest barrier - until now. (Available late this year to all Makera users)
Explore a World of Designs
Makerables, Makera's CNC Project Sharing Platform. 3D printing already has mature sharing platforms. CNC deserves one too, so we built it.
AI-Powered Workflow
Customize CNC Models with Zero Modeling Skills. Experience the AI-powered workflow and create stunning crafts like a pro. (Available late this year to all Makera users)
As Seen In
Specifications
| Dimensions | |
| Work Area | 200mm(X) * 200mm(Y) * 100mm(Z) / 7.9in * 7.9in * 3.9in |
| 4th Axis Work Area (optional) | 80mm(Diameter) * 150mm(Length) / 3.1in * 5.9in |
| Gantry Clearance | 115mm / 4.5in |
| Max Height (Lid open) | 84cm / 33in |
| Footprint | 350mm(Width) * 470mm(Depth) * 450mm(Height) / 13.8in * 18.5in * 17.7in |
| Weight | 17kg |
| Spindle | |
| Power | 150 Watt |
| Speed | 0 - 13000 RPM with closed-loop control |
| Collet | Custom collet with ⅛in integrated (optional: ¼in, 6mm, 4mm) |
| Tool Change Method | Quick tool changer |
| Cooling | Built-in air cooling |
| Motion System | |
| Motor | NEMA 17 stepper motor |
| Drive Method | Linear rails + Acme lead screw |
| 4th Axis Drive Method (Optional) | Belt driven |
| Precision | |
| Spindle Runout | 0.01mm / 0.0004in |
| Resolution | 0.02mm / 0.0008in |
| Laser Module (optional) | |
| Power | 5 Watt |
| Laser Type | 445nm semiconductor diode laser |
| Dust Collection | |
| AeroDust™ Collection System | Integrated spindle & tool cooling with active chip evacuation and dust collection. |
| Supported Materials | |
| Metal | Aluminum, brass, copper and other Non-Ferrous metals. |
| Wood | Hardwoods, softwoods, MDF, plywoods, etc. |
| Plastic | Foam, PVC, ABS, Acrylic, PC, HDPE, etc. |
| Composite material | Carbon fiber, FR4, etc. |
| Laser engrave material | Wood, plastic, fabric, leather, cardboard, etc. |
| Software | |
| Makera Studio — the new Makera CAM. | Makera's first one-click consumer CAM software — available free to all Makera users. |
| Compatible CAD/CAM software: | Fusion360, SolidWorks, AutoCad, VCarve Pro, Aspire, Illustrator, etc. |
| Makera App — the new Makera Controller | Makera's mobile app lets you control and monitor your machine remotely. |
| Makerables | A universal CNC project-sharing platform from Makera. |
| AI Craft | Makera's AI tool lets you Customize CNC Models with Zero Modeling Skills. |
